Purify, protect, regulate, and rebuild unrestricted new power from old. The DirectStream P15 Power Plant is the gold standard for safety, reliability, and high-performance AC power regeneration. The P15 improves micro and macro dynamics, audio purity, instrumental separation, soundstage width and depth, and lowers background noise for any connected equipment. The P15 is the successor to the venerable P10 Power Plant, a tireless performer faithfully powering thousands of high-performance audio and video system around the world for nearly a decade. The P15 has been completely redesigned from the ground up with three times lower output impedance, lower distortion, a new FPGA based DSD sine wave generator, and an improved level of performance never before attained by any Power Plant of its size. If high-performance audio or video is your goal, there’s no better foundation for any system than a Power Plant AC regenerator.
Specifications
Environment Specification | US/JP |
Location | Indoor use only |
Duty Cycle | Suitable for continuous operation |
Moisture Sensitivity | Not sealed against moisture |
Operating Humidity | <80%rh |
Storage Temperature | -40C to +40C |
Operating Temperature | 0C to 40C |
Max Operating Altitude | 12,000’ (3500m) |
Electrical Supply Nominal Rating | 120V 15A 60Hz US |
Instrument Specification | |
Unit Dimensions | 17” W x 14” D x 8.5” H (43cm W x 36cm D x 21.5 cm H) |
Unit Weight | 73 lbs ( 33kg) |
Shipping Dimensions | 23” x 20.5” x 13.5” ( 58cm x 52cm x 34cm) |
Shipping Weight | 82 lbs (38kg) |
Nominal Input Voltage | 95 – 145 VAC |
Maximum Continuous Load | 1200VA |
Maximum Peak Load | 3600VA |
Voltage Regulation | 1V |
Output Distortion (Resistive Load) | <0.5% |
Output Distortion (Reactive Load) | <0.5% |
Output Impedance | <0.008 ohm |
Noise Reduction | 100kHz – 2MHz >80dB |
Efficiency @1200 VA | >85% |
Standby Power Consumption | |
Input Frequency | 45 – 65 Hz |
Under Voltage Limit | Continuous -10% of setting 15 sec duration -15% of setting |
Over Voltage Limit | Continuous 5% of setting 15 sec duration 10% of setting |
Energy Dissipation | 2440J |
Peak Current Surge | 144,000A |
Max Surge Voltage | 6,000V |
Clamp Level | 330V |
DC Trigger Configuration | Tip Positive |
DC Trigger Voltage | 5 – 15Vdc |
