Demanding systems require remarkable power. The DirectStream P20 Power Plant is our finest expression of the art of delivering protected, pure, regulated, distortion-free AC power. With peak power levels of 3600 watts, no equipment can tax the mighty P20. Finally, your most coveted components have the opportunity to unleash their full potential, no longer hindered by dynamic drops in AC caused by the unavoidable resistance of the miles of wiring between you and the power station. DirectStream P20 regulates both long-term fluctuations and peak dynamic without deviation, ensuring a solid foundation from which to build a state-of-the-art system. Its low output impedance and unhindered AC delivery are equivalent to less than 50 feet of 12 gauge wire connected directly to your city power source without the connecting miles of wire, the many transformers, and the multiple neighbors weakening and contaminating your power. The most demanding music systems require nothing less than the P20.
Specifications
Environment Specification | US/JP |
Location | Indoor use only |
Duty Cycle | Suitable for continuous operation |
Moisture Sensitivity | Not sealed against moisture |
Operating Humidity | <80%rh |
Storage Temperature | -40C to +40C |
Operating Temperature | 0C to 40C |
Max Operating Altitude | 12,000’ (3500m) |
Electrical Supply Nominal Rating | 120V 15A 60Hz US |
Instrument Specification | |
Unit Dimensions | 17” W x 14” D x 11” H (43cm W x 36cm D x 27.9 cm H) |
Unit Weight | 96 lbs ( 43.5kg) |
Shipping Dimensions | 23” x 22” x 17” ( 58cm x 55.8cm x 43 cm) |
Shipping Weight | 105 lbs (47kg) |
Nominal Input Voltage | 95 – 145 VAC |
Maximum Continuous Load | 2000VA |
Maximum Peak Load | 3600VA |
Voltage Regulation | >1V |
Output Distortion (Resistive Load) | <0.5% |
Output Distortion (Reactive Load) | <0.5% |
Output Impedance | <0.005 ohm |
Noise Reduction | 100kHz – 2MHz >80dB |
Efficiency @1500 VA | >85% |
Standby Power Consumption | |
Input Frequency | 45 – 65 Hz |
Under Voltage Limit | Continuous -10% of setting 15 sec duration -15% of setting |
Over Voltage Limit | Continuous 5% of setting 15 sec duration 10% of setting |
Energy Dissipation | 2040J |
Peak Current Surge | 180,000A |
Clamp Level | 340V |
DC Trigger Configuration | Tip Positive |
DC Trigger Voltage | 5 – 15Vdc |
