Drawing on their 30 years of experience of designing transistor circuits, Hegel has developed the V10 phono preamp completely from the ground up. Their goal was to bring their well known sound: neutral, dynamic, and low distortion, and allow users to now listen to their favourite records. Hegel claims the V10 will "give you an unprecedented transparency and soundscape - Making the music you hear as tangible and real as the record it is pressed into"
MM and MC
Subsonic Filter
Balanced (XLR) output
Highly optimizable
Auto standby
Specifications
Technical Specifications | |
Amplifier Typology | Ultra low noise discrete JFET transistor input stage for both MC and MM |
Gain XLR Out MM | 40dB / 45dB / 50dB / 52dB |
Gain XLR Out MC | 60dB / 65dB / 70dB / 72dB |
Gain RCA Out MM | 34dB / 39dB / 44dB / 46dB |
Gain RCA Out MC | 54dB / 59dB / 64dB / 66dB |
MC Load Impedance | Freely adjustable between 33 and 550 ohm / 47 kohm |
MM Load Capacitance | 100pF / 147pF / 220pF / 247pF / 320pF / 420pF / 467pF @ 47 kohm |
Subsonic Filter | Switchable on / off, -3dB at 20Hz, -18dB octave |
RIAA Accuracy | +/- 0,2dB / 20Hz - 20kHz |
Output Noise* | -84dB/MM ("A" weighted ref: 0dBV), -81dB/MC ("A" weighted ref: 0dBV) |
Output Impedance XLR / RCA | 200 ohm |
Channel Crosstalk | -84dB @1kHz 0dBV |
Frequency Response | 2Hz - 20kHz |
Distortion (THD) MM | < 0.005% @1kHz 0dBV |
Distortion (THD) MC | < 0.009% @1kHz 0dBV |
Inputs | 1 x unbalanced (RCA) MM, 1 x unbalanced (RCA) MC |
Outputs | 1 x unbalanced fixed (RCA), 1 x balanced fixed (XLR) |
Power Adapter | Hegel Power Adapter M30103 |
Dimensions with Feet | 6cm x 21cm x 28cm, 2.4" x 8,3" x 11" (H x W x D) |
Weight | 2,2kg / 4,9lbs unit weight |
* When stable operating temperature has been reached | |
